Stepper

A sequence of steps that shows where the user is in a multi-stage flow.

import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [1, 2, 3, 4];

export default function Particle() {
  return (
    <div className="mx-auto w-full max-w-xl">
      <Stepper defaultValue={2}>
        {steps.map((step) => (
          <StepperItem className="not-last:flex-1" key={step} step={step}>
            <StepperTrigger>
              <StepperIndicator />
            </StepperTrigger>
            {step < steps.length && <StepperSeparator />}
          </StepperItem>
        ))}
      </Stepper>
    </div>
  );
}

Usage

import {
  Stepper,
  StepperDescription,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTitle,
  StepperTrigger,
} from "mako-ui/components/stepper"

<Stepper defaultValue={2}>
  <StepperItem className="not-last:flex-1" step={1}>
    <StepperTrigger>
      <StepperIndicator />
      <StepperTitle>Account</StepperTitle>
    </StepperTrigger>
    <StepperSeparator />
  </StepperItem>
  <StepperItem className="not-last:flex-1" step={2}>
    <StepperTrigger>
      <StepperIndicator />
      <StepperTitle>Delivery</StepperTitle>
    </StepperTrigger>
    <StepperSeparator />
  </StepperItem>
  <StepperItem step={3}>
    <StepperTrigger>
      <StepperIndicator />
      <StepperTitle>Payment</StepperTitle>
    </StepperTrigger>
  </StepperItem>
</Stepper>

Steps are numbered from 1. Every step below the active one is completed, the active one is highlighted, and the ones above it are inactive. Clicking a StepperTrigger makes its step the active one; leave the trigger out and drive value from your own controls for a read-only stepper.

API Reference

This is a custom component.

Stepper

Root ordered list. Holds the active step and the orientation and exposes both to its items through data-orientation.

Prop	Type	Default	Description
`defaultValue`	`number`	`1`	The step active on first render, when uncontrolled
`value`	`number`	-	The active step, when controlled
`onValueChange`	`(step: number) => void`	-	Called with the step whose trigger was activated
`orientation`	`"horizontal" \| "vertical"`	`"horizontal"`	Lays the steps out in a row or in a column

StepperItem

List item for one step. Derives its state from step and the active step and exposes it as data-state (completed, active or inactive), plus data-orientation, data-disabled and data-loading.

Prop	Type	Default	Description
`step`	`number`	-	The 1-based position of the step. Required
`completed`	`boolean`	`false`	Marks the step completed whatever the active step is
`disabled`	`boolean`	`false`	Disables the step's trigger
`loading`	`boolean`	`false`	Shows a spinner in the indicator while this step is active

StepperTrigger

Button that makes its step the active one. Carries aria-current="step" while active, is disabled with its item, and supports the render prop for links.

StepperIndicator

The step marker. Shows the step number by default, swaps it for a checkmark once the step is completed and for a spinner while it is loading. Pass children to replace that content: a string or number keeps the number styling without the checkmark, anything else, such as an icon, an avatar or a visually hidden label under a progress bar, renders as is.

import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [1, 2, 3, 4];

export default function Particle() {
  return (
    <div className="mx-auto w-full max-w-xl">
      <Stepper defaultValue={2}>
        {steps.map((step) => (
          <StepperItem className="not-last:flex-1" key={step} step={step}>
            <StepperTrigger>
              <StepperIndicator>{step}</StepperIndicator>
            </StepperTrigger>
            {step < steps.length && <StepperSeparator />}
          </StepperItem>
        ))}
      </Stepper>
    </div>
  );
}

Tiny indicators

import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [1, 2, 3, 4];

export default function Particle() {
  return (
    <div className="mx-auto w-full max-w-xl">
      <Stepper defaultValue={2}>
        {steps.map((step) => (
          <StepperItem className="not-last:flex-1" key={step} step={step}>
            <StepperTrigger>
              <StepperIndicator className="size-4 data-[state=active]:border-2 data-[state=active]:border-primary data-[state=active]:bg-transparent *:data-[slot=stepper-indicator-number]:sr-only *:data-[slot=stepper-indicator-check]:size-3" />
            </StepperTrigger>
            {step < steps.length && <StepperSeparator />}
          </StepperItem>
        ))}
      </Stepper>
    </div>
  );
}

Controlled

"use client";

import { Button } from "mako-ui/components/button";
import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
} from "mako-ui/components/stepper";
import { useState } from "react";

const steps = [1, 2, 3, 4];

export default function Particle() {
  const [currentStep, setCurrentStep] = useState(2);

  return (
    <div className="mx-auto flex w-full max-w-xl flex-col items-center gap-8">
      <Stepper onValueChange={setCurrentStep} value={currentStep}>
        {steps.map((step) => (
          <StepperItem className="not-last:flex-1" key={step} step={step}>
            <StepperIndicator />
            {step < steps.length && <StepperSeparator />}
          </StepperItem>
        ))}
      </Stepper>
      <div className="flex gap-4">
        <Button
          className="w-32"
          disabled={currentStep === 1}
          onClick={() => setCurrentStep((step) => step - 1)}
          variant="outline"
        >
          Previous
        </Button>
        <Button
          className="w-32"
          disabled={currentStep > steps.length}
          onClick={() => setCurrentStep((step) => step + 1)}
          variant="outline"
        >
          Next
        </Button>
      </div>
    </div>
  );
}

Loading step

"use client";

import { Button } from "mako-ui/components/button";
import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
} from "mako-ui/components/stepper";
import { useState } from "react";

const steps = [1, 2, 3, 4];

export default function Particle() {
  const [currentStep, setCurrentStep] = useState(2);
  const [loading, setLoading] = useState(false);

  const goToNextStep = () => {
    setLoading(true);
    setTimeout(() => {
      setCurrentStep((step) => step + 1);
      setLoading(false);
    }, 1000);
  };

  return (
    <div className="mx-auto flex w-full max-w-xl flex-col items-center gap-8">
      <Stepper onValueChange={setCurrentStep} value={currentStep}>
        {steps.map((step) => (
          <StepperItem
            className="not-last:flex-1"
            key={step}
            loading={loading}
            step={step}
          >
            <StepperIndicator />
            {step < steps.length && <StepperSeparator />}
          </StepperItem>
        ))}
      </Stepper>
      <div className="flex gap-4">
        <Button
          className="w-32"
          disabled={currentStep === 1 || loading}
          onClick={() => setCurrentStep((step) => step - 1)}
          variant="outline"
        >
          Previous
        </Button>
        <Button
          className="w-32"
          disabled={currentStep > steps.length}
          loading={loading}
          onClick={goToNextStep}
          variant="outline"
        >
          Next
        </Button>
      </div>
    </div>
  );
}

Mixed indicators

import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTrigger,
} from "mako-ui/components/stepper";
import { Truck } from "mako-ui/icons/truck";

export default function Particle() {
  return (
    <div className="mx-auto w-full max-w-xl">
      <Stepper defaultValue={2}>
        <StepperItem className="not-last:flex-1" step={1}>
          <StepperTrigger>
            <StepperIndicator className="size-8">
              <img
                alt="Luke Tracy"
                className="size-8 rounded-full object-cover"
                height={32}
                src="/images/portrait-1.jpg"
                width={32}
              />
            </StepperIndicator>
          </StepperTrigger>
          <StepperSeparator />
        </StepperItem>
        <StepperItem className="not-last:flex-1" loading step={2}>
          <StepperTrigger>
            <StepperIndicator />
          </StepperTrigger>
          <StepperSeparator />
        </StepperItem>
        <StepperItem className="not-last:flex-1" step={3}>
          <StepperTrigger>
            <StepperIndicator>
              <Truck aria-hidden="true" />
              <span className="sr-only">Delivery</span>
            </StepperIndicator>
          </StepperTrigger>
        </StepperItem>
      </Stepper>
    </div>
  );
}

Labels

import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperTitle,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [
  { step: 1, title: "Account" },
  { step: 2, title: "Delivery" },
  { step: 3, title: "Payment" },
  { step: 4, title: "Review" },
];

export default function Particle() {
  return (
    <div className="mx-auto w-full max-w-xl">
      <Stepper className="items-start gap-4" defaultValue={2}>
        {steps.map(({ step, title }) => (
          <StepperItem className="flex-1" key={step} step={step}>
            <StepperTrigger className="w-full flex-col items-start gap-2 rounded">
              <StepperIndicator className="h-1 w-full">
                <span className="sr-only">{step}</span>
              </StepperIndicator>
              <StepperTitle>{title}</StepperTitle>
            </StepperTrigger>
          </StepperItem>
        ))}
      </Stepper>
    </div>
  );
}

Paginated

"use client";

import { Button } from "mako-ui/components/button";
import {
  Stepper,
  StepperIndicator,
  StepperItem,
} from "mako-ui/components/stepper";
import { ArrowChevronLeft } from "mako-ui/icons/arrow-chevron-left";
import { ArrowChevronRight } from "mako-ui/icons/arrow-chevron-right";
import { useState } from "react";

const steps = [1, 2, 3, 4];

export default function Particle() {
  const [currentStep, setCurrentStep] = useState(2);

  return (
    <div className="mx-auto flex w-full max-w-xl items-center gap-2">
      <Button
        aria-label="Previous step"
        className="shrink-0"
        disabled={currentStep === 1}
        onClick={() => setCurrentStep((step) => step - 1)}
        size="icon"
        variant="ghost"
      >
        <ArrowChevronLeft aria-hidden="true" />
      </Button>
      <Stepper
        className="gap-1"
        onValueChange={setCurrentStep}
        value={currentStep}
      >
        {steps.map((step) => (
          <StepperItem className="flex-1" key={step} step={step}>
            <StepperIndicator className="h-1 w-full">
              <span className="sr-only">{step}</span>
            </StepperIndicator>
          </StepperItem>
        ))}
      </Stepper>
      <Button
        aria-label="Next step"
        className="shrink-0"
        disabled={currentStep === steps.length}
        onClick={() => setCurrentStep((step) => step + 1)}
        size="icon"
        variant="ghost"
      >
        <ArrowChevronRight aria-hidden="true" />
      </Button>
    </div>
  );
}

Progress

Step 1 of 4

"use client";

import { Button } from "mako-ui/components/button";
import {
  Stepper,
  StepperIndicator,
  StepperItem,
} from "mako-ui/components/stepper";
import { useState } from "react";

const steps = [1, 2, 3, 4];

export default function Particle() {
  const [currentStep, setCurrentStep] = useState(1);

  return (
    <div className="mx-auto flex w-full max-w-xl flex-col items-center gap-8">
      <div className="flex w-full flex-col gap-3">
        <Stepper onValueChange={setCurrentStep} value={currentStep}>
          {steps.map((step) => (
            <StepperItem className="flex-1" key={step} step={step}>
              <StepperIndicator className="h-2 w-full rounded-none">
                <span className="sr-only">{step}</span>
              </StepperIndicator>
            </StepperItem>
          ))}
        </Stepper>
        <p
          aria-live="polite"
          className="font-medium text-muted-foreground text-sm tabular-nums"
        >
          Step {currentStep} of {steps.length}
        </p>
      </div>
      <div className="flex gap-4">
        <Button
          className="w-32"
          disabled={currentStep === 1}
          onClick={() => setCurrentStep((step) => step - 1)}
          variant="outline"
        >
          Previous
        </Button>
        <Button
          className="w-32"
          disabled={currentStep >= steps.length}
          onClick={() => setCurrentStep((step) => step + 1)}
          variant="outline"
        >
          Next
        </Button>
      </div>
    </div>
  );
}

Titles and descriptions

import {
  Stepper,
  StepperDescription,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTitle,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [
  { description: "Sign in or register", step: 1, title: "Account" },
  { description: "Address and shipping", step: 2, title: "Delivery" },
  { description: "Card or invoice", step: 3, title: "Payment" },
];

export default function Particle() {
  return (
    <div className="mx-auto w-full max-w-xl">
      <Stepper defaultValue={2}>
        {steps.map(({ step, title, description }) => (
          <StepperItem
            className="relative flex-1 flex-col"
            key={step}
            step={step}
          >
            <StepperTrigger className="flex-col gap-3 rounded">
              <StepperIndicator />
              <div className="flex flex-col gap-0.5 px-2 text-center">
                <StepperTitle>{title}</StepperTitle>
                <StepperDescription className="max-sm:hidden">
                  {description}
                </StepperDescription>
              </div>
            </StepperTrigger>
            {step < steps.length && (
              <StepperSeparator className="absolute inset-s-[calc(50%+0.875rem)] top-3 m-0 w-[calc(100%-1.75rem)] flex-none -translate-y-1/2" />
            )}
          </StepperItem>
        ))}
      </Stepper>
    </div>
  );
}

Inline titles

import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTitle,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [
  { step: 1, title: "Account" },
  { step: 2, title: "Delivery" },
  { step: 3, title: "Payment" },
];

export default function Particle() {
  return (
    <div className="mx-auto w-full max-w-xl">
      <Stepper defaultValue={2}>
        {steps.map(({ step, title }) => (
          <StepperItem
            className="not-last:flex-1 max-md:items-start"
            key={step}
            step={step}
          >
            <StepperTrigger className="rounded max-md:flex-col">
              <StepperIndicator />
              <StepperTitle className="text-center md:text-start">
                {title}
              </StepperTitle>
            </StepperTrigger>
            {step < steps.length && (
              <StepperSeparator className="max-md:mt-3.5 md:mx-4" />
            )}
          </StepperItem>
        ))}
      </Stepper>
    </div>
  );
}

Inline titles and descriptions

import {
  Stepper,
  StepperDescription,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTitle,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [
  { description: "Sign in or register", step: 1, title: "Account" },
  { description: "Address and shipping", step: 2, title: "Delivery" },
  { description: "Card or invoice", step: 3, title: "Payment" },
];

export default function Particle() {
  return (
    <div className="mx-auto w-full max-w-xl">
      <Stepper defaultValue={2}>
        {steps.map(({ step, title, description }) => (
          <StepperItem
            className="not-last:flex-1 max-md:items-start"
            key={step}
            step={step}
          >
            <StepperTrigger className="rounded max-md:flex-col">
              <StepperIndicator />
              <div className="text-center md:text-start">
                <StepperTitle>{title}</StepperTitle>
                <StepperDescription className="max-sm:hidden">
                  {description}
                </StepperDescription>
              </div>
            </StepperTrigger>
            {step < steps.length && (
              <StepperSeparator className="max-md:mt-3.5 md:mx-4" />
            )}
          </StepperItem>
        ))}
      </Stepper>
    </div>
  );
}

Vertical

import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [1, 2, 3, 4];

export default function Particle() {
  return (
    <Stepper defaultValue={2} orientation="vertical">
      {steps.map((step) => (
        <StepperItem className="not-last:flex-1" key={step} step={step}>
          <StepperTrigger>
            <StepperIndicator />
          </StepperTrigger>
          {step < steps.length && <StepperSeparator />}
        </StepperItem>
      ))}
    </Stepper>
  );
}

Controlled vertical

"use client";

import { Button } from "mako-ui/components/button";
import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
} from "mako-ui/components/stepper";
import { useState } from "react";

const steps = [1, 2, 3, 4];

export default function Particle() {
  const [currentStep, setCurrentStep] = useState(1);

  return (
    <div className="flex flex-col items-center gap-8">
      <Stepper
        onValueChange={setCurrentStep}
        orientation="vertical"
        value={currentStep}
      >
        {steps.map((step) => (
          <StepperItem className="not-last:flex-1" key={step} step={step}>
            <StepperIndicator />
            {step < steps.length && <StepperSeparator />}
          </StepperItem>
        ))}
      </Stepper>
      <div className="flex gap-4">
        <Button
          className="w-32"
          disabled={currentStep === 1}
          onClick={() => setCurrentStep((step) => step - 1)}
          variant="outline"
        >
          Previous
        </Button>
        <Button
          className="w-32"
          disabled={currentStep > steps.length}
          onClick={() => setCurrentStep((step) => step + 1)}
          variant="outline"
        >
          Next
        </Button>
      </div>
    </div>
  );
}

Vertical with inline titles

import {
  Stepper,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTitle,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [
  { step: 1, title: "Account" },
  { step: 2, title: "Delivery" },
  { step: 3, title: "Payment" },
  { step: 4, title: "Review" },
];

export default function Particle() {
  return (
    <Stepper defaultValue={2} orientation="vertical">
      {steps.map(({ step, title }) => (
        <StepperItem
          className="relative not-last:flex-1 items-start"
          key={step}
          step={step}
        >
          <StepperTrigger className="items-start rounded pb-12 last:pb-0">
            <StepperIndicator />
            <StepperTitle className="mt-0.5 px-2 text-start">
              {title}
            </StepperTitle>
          </StepperTrigger>
          {step < steps.length && (
            <StepperSeparator className="absolute inset-s-3 top-[calc(1.5rem+0.125rem)] m-0 h-[calc(100%-1.75rem)] -translate-x-1/2" />
          )}
        </StepperItem>
      ))}
    </Stepper>
  );
}

Vertical with inline titles and descriptions

import {
  Stepper,
  StepperDescription,
  StepperIndicator,
  StepperItem,
  StepperSeparator,
  StepperTitle,
  StepperTrigger,
} from "mako-ui/components/stepper";

const steps = [
  { description: "Sign in or register", step: 1, title: "Account" },
  { description: "Address and shipping", step: 2, title: "Delivery" },
  { description: "Card or invoice", step: 3, title: "Payment" },
];

export default function Particle() {
  return (
    <Stepper defaultValue={2} orientation="vertical">
      {steps.map(({ step, title, description }) => (
        <StepperItem
          className="relative not-last:flex-1 items-start"
          key={step}
          step={step}
        >
          <StepperTrigger className="items-start rounded pb-12 last:pb-0">
            <StepperIndicator />
            <div className="mt-0.5 flex flex-col gap-0.5 px-2 text-start">
              <StepperTitle>{title}</StepperTitle>
              <StepperDescription>{description}</StepperDescription>
            </div>
          </StepperTrigger>
          {step < steps.length && (
            <StepperSeparator className="absolute inset-s-3 top-[calc(1.5rem+0.125rem)] m-0 h-[calc(100%-1.75rem)] -translate-x-1/2" />
          )}
        </StepperItem>
      ))}
    </Stepper>
  );
}

Stepper

Usage

API Reference

Stepper

StepperItem

StepperTrigger

StepperIndicator

StepperTitle

StepperDescription

StepperSeparator

Examples

Numbers only

Tiny indicators

Controlled

Loading step

Mixed indicators

Labels

Paginated

Progress

Titles and descriptions

Inline titles

Inline titles and descriptions

Vertical

Controlled vertical

Vertical with inline titles

Vertical with inline titles and descriptions
